Double Leg Pallet
Heavy-Duty 2-Way Entry Flat Pallet for Warehousing & Logistics
The double leg pallet is a heavy-duty flat pallet built on two longitudinal steel legs (runners) instead of a full bottom deck. This open-bottom structure gives the pallet an excellent strength-to-weight ratio, keeps the fork pockets clear on two opposite sides, and makes it one of the most cost-effective solutions for warehouse storage, racking and freight transport. Every double leg pallet is automatically formed, welded and powder-coated as a single integrated unit - and each dimension, load rating and color can be customized to your exact application.
What Is a Double Leg Pallet?
A double leg pallet is a single-deck (flat) pallet whose entire load is carried by two parallel longitudinal legs running the full length of the pallet, hence the name "double leg". The top deck consists of 9 reinforced boards welded onto these two legs, and there is no bottom deck underneath. Because the legs sit at the two edges, forks can only enter from the two opposite ends - a 2-way entry design that maximizes deck strength while keeping the pallet light and affordable.
Compared with nine-foot or double-faced pallets, the double leg design removes unnecessary bottom structure, which reduces weight and cost, speeds up handling, and simplifies cleaning. It is the preferred flat pallet for heavy machinery parts, building materials, chemicals and high-density racking, where load capacity and durability matter more than four-way flexibility.
Key Features & Benefits
Integrated automatic molding - intelligent, fully automatic production line; every unit is dimensionally precise with consistent quality and high cost performance.
Automatic welding + powder coating - solid, burr-free welds and an electrostatic plastic-sprayed finish that resists rust, chemicals and daily forklift impact.
High precision, high friction coefficient - the deck surface grips cartons, drums and bags to keep loads stable during transport and stacking.
High & low temperature resistance - performs reliably in cold stores and hot workshops alike; fully moisture-proof and pest-proof, with no rot, mold or insect damage.
Tested to international standards - every batch is verified at an international packaging research and testing center for static, dynamic and racking performance.
Lightweight design options - optimized profiles cut dead weight (and freight cost) without sacrificing rated capacity.
Wood-free export option - the all-steel version contains no wood, so it needs no ISPM-15 fumigation or heat treatment and clears customs without delays.
Technical Specifications
| Parameter | Specification |
|---|---|
| Structure options | All-steel / steel-wood / steel-plastic composite / lightweight design |
| Top deck boards | 9 |
| Longitudinal legs (runners) | 2 (double-leg design) |
| Bottom deck boards | 0 - open-bottom single-deck structure |
| Fork entry type | 2-way (two opposite ends, for forklift and hand pallet truck) |
| Standard sizes (L × W, mm) | 1200×1000 · 1200×800 · 1100×1100 · 1165×1165 - customization supported |
| Load ratings | 1 t / 1.5 t / 2 t / 4 t / 5 t - customization supported |
| Surface treatment | Automatic welding + electrostatic powder coating (plastic spraying) |
| Color | Customizable (blue, orange, gray, green or any RAL color) |
| Quality standard | Tested at an international packaging research & testing center; conforms to international standards |
Standard Sizes & Load Rating Chart
| Model | Size (L×W, mm) | Load options | Fork entry | Typical use |
|---|---|---|---|---|
| DLP-1210 | 1200 × 1000 | 1 / 1.5 / 2 / 4 / 5 t | 2-way | Standard 40' container & EU-compatible loads |
| DLP-1208 | 1200 × 800 | 1 / 1.5 / 2 / 4 t | 2-way | EUR-pallet footprint, narrow aisles |
| DLP-1111 | 1100 × 1100 | 1 / 1.5 / 2 / 4 t | 2-way | Drums, IBC-compatible square footprint |
| DLP-1165 | 1165 × 1165 | 1 / 1.5 / 2 / 4 / 5 t | 2-way | Heavy machinery & metal components |
| Custom | Any size on request | Any rating on request | 2-way | Project-specific designs & OEM |
Structure Options: All-Steel, Steel-Wood, Steel-Plastic or Lightweight
| Structure | Construction | Weight class | Best suited for |
|---|---|---|---|
| All-steel | Steel deck + steel legs, welded and powder-coated | Heavy | 4–5 t heavy duty, long-term racking, outdoor and cold-chain storage |
| Steel-wood | Steel legs + wooden top boards | Medium | General warehousing, cost-sensitive projects, non-humid environments |
| Steel-plastic | Steel core + plastic (PE/PP) top deck | Medium | Food, pharmaceutical and chemical plants; humid or wash-down areas |
| Lightweight | Optimized thin-wall steel profile | Light | ≈1 t loads, export shipping, one-way logistics, light goods turnover |
How the Double Leg Pallet Compares with Other Pallet Types
| Feature | Double Leg Pallet | Wood Pallet | Injection Plastic Pallet | Double-Faced Pallet |
|---|---|---|---|---|
| Max load | Up to 5 t | Typically 1–1.5 t | Typically 1–1.5 t | Up to 5 t, but heavier |
| Moisture & pest proof | Yes | No | Yes | Yes |
| Size customization | Full custom | Limited | Restricted by mold | Limited |
| Service life | Long, replaceable deck boards | Short, splinters & rot | Long but hard to repair | Long, heavy to handle |
| Repairability | Weldable, boards replaceable | Partly repairable | Not repairable | Weldable |
| Export (ISPM-15) | Steel version: exempt | Fumigation required | Exempt | Steel version: exempt |
Applications
Products Description
Warehouse racking & floor stacking - rigid two-leg base keeps pallets square on beams and stable in high stacks.
Machinery, hardware & metal parts - 2–5 t ratings handle dense, heavy industrial goods.
Chemicals, building materials & drums - moisture-proof, chemical-resistant powder coating.
Cold-chain & food logistics - all-steel and steel-plastic versions withstand low-temperature storage and wash-down cleaning.
Export & one-way shipping - wood-free steel pallets pass customs without ISPM-15 treatment.
Customization Options
Dimensions - any length × width beyond the four standard sizes, matched to your goods, racks or containers.
Load rating - from 1 t to 5 t and beyond, engineered to your stacking and racking requirements.
Structure - all-steel, steel-wood, steel-plastic or lightweight, selected per application.
Color & finish - any RAL powder-coat color; anti-slip or special-surface options on request.
Marking - company name, logo or serial numbers welded, stamped or sprayed for asset tracking.
FAQ
Q: What does "double leg" mean on a pallet?
A: "Double leg" refers to the two longitudinal legs (runners) that carry the entire top deck. With 9 boards resting on these 2 legs and no bottom deck, the pallet achieves a high load capacity with minimum material - hence 2-way fork entry and an excellent strength-to-cost ratio.
Q: Can forklifts and pallet trucks handle it from all four sides?
A: No - the double leg pallet is a 2-way entry pallet. Forklifts and hand pallet trucks enter from the two opposite ends where the fork pockets are located. If you need four-way access, we can quote a four-way or double-faced pallet instead.
Q: What load capacities are available?
A: Standard ratings are 1 t, 1.5 t, 2 t, 4 t and 5 t (static). Dynamic and racking loads depend on the structure and size you choose - tell us your goods weight and stacking height and we will recommend the right specification.
Q: Is the double leg pallet suitable for export?
A: Yes. The all-steel and steel-plastic versions contain no wood at all, so they are exempt from ISPM-15 fumigation and heat treatment. The steel-wood version uses wooden deck boards and follows the wood packing rules of the destination country.
Q: Which structure should I choose - steel, steel-wood or steel-plastic?
A: Choose all-steel for maximum load and outdoor or cold-store use; steel-wood for economical general warehousing; steel-plastic for food, pharmaceutical and humid environments where hygiene and wash-down cleaning matter.
Q: Can I order custom sizes, colors and logos?
A: Yes. Sizes, load ratings, RAL colors, structures and logo marking are all customizable. MOQ is flexible for standard models - send us your drawings or requirements for a same-day quotation.
Request a Free Quote for Double Leg Pallets
Tell us your size, load and structure requirements - our engineers will confirm the specification and provide factory-direct pricing within 24 hours.
